Product number: 24.0325-0141.1
|
EAN: 4006633120371
Properties
Alles weergeven
|
|
Height (mm)
Height (mm)
|
42.1 |
|
Outer diameter (mm)
Outer diameter (mm)
|
285.0 |
|
Inner diameter (mm)
Inner diameter (mm)
|
139.0 |
|
Brake disc type
Brake disc type
|
vented |
|
Brake disc thickness (mm)
Brake disc thickness (mm)
|
24.9 |
|
Num. of holes
Num. of holes
|
5 |
|
Bore Ø (mm)
Bore Ø (mm)
|
14.0 |
|
Supplementary article/info 2
Supplementary article/info 2
|
with bolts/screws |
|
Bolt hole circle Ø (mm)
Bolt hole circle Ø (mm)
|
110.0 |
|
Min. thickness (mm)
Min. thickness (mm)
|
22.0 |
|
Surface
Surface
|
coated |
|
Appr. stamp
Appr. stamp
|
e1 90r-02c0858/1210 |
|
Centering diameter (mm)
Centering diameter (mm)
|
70.0 |
|
Machining
Machining
|
high-carbon |
|
Weight
Weight
|
6.76 kg |
