Product number: 24.0130-0255.1
|
EAN: 4006633482363
Properties
Alles weergeven
|
|
Height (mm)
Height (mm)
|
45.0 |
|
Outer diameter (mm)
Outer diameter (mm)
|
345.0 |
|
Inner diameter (mm)
Inner diameter (mm)
|
160.0 |
|
Brake disc type
Brake disc type
|
vented |
|
Brake disc thickness (mm)
Brake disc thickness (mm)
|
30.0 |
|
Num. of holes
Num. of holes
|
5 |
|
Bore Ø (mm)
Bore Ø (mm)
|
16.0 |
|
Bolt hole circle Ø (mm)
Bolt hole circle Ø (mm)
|
120.0 |
|
Min. thickness (mm)
Min. thickness (mm)
|
27.0 |
|
Surface
Surface
|
coated |
|
Appr. stamp
Appr. stamp
|
e1 90r-02c0115/1181 |
|
Centering diameter (mm)
Centering diameter (mm)
|
67.2 |
|
Machining
Machining
|
high-carbon |
|
Weight
Weight
|
11.64 kg |
